FLOWORK Check Valves are in various types, sizes and pressure to be applied to different sectors. Our valves are in high quality and are highly preferred by customers, complying with the strictest international standards involving API 602, API 6D, API 594, API-Q1, CE, ISO 9001, ISO 45001, ISO 14001, etc. We can also produce customized check valves to meet specific industrial requirements.
Read MoreFLOWORK is accredited by renowned global organizations and certified by strict international standards involving API 600, API 6D, API-Q1, API 607, API 6FA, CE, ISO 9001, ISO 45001, ISO 14001, ISO 15848-1, etc.
FLOWORK check valves are tested in compliance with the requirements of the strictest test organizations (TUV, SGS, ABS, DNV, etc.).
Some items of check valves are in stock, so we can deliver prompt and meet customers’ urgent needs. Effectively prevent medium backflow; occupy little space.
We mainly produce carbon steel (WCB, LCB, A105, LF2, etc.), alloy steel (WC6, WC9, C5, F11, F22, F5, etc.), stainless steel (CF8, CF8M, 4A, 5A, F304, F316, F51, F53, etc.), bronze (C95800, C95500, C83600, etc.).
Yes, we can provide a material report EN 10204 3.1 certificate after the valve is completed.
Yes, we have portable PMI machines.
Yes, as long as the customer requests the test bars, we will prepare it during production.
We are only responsible for the material and valve pressure rating specified on the order. Customers should choose suitable materials and pressure grades according to working temperature, working pressure and working medium.
Our warranty is 12 months after the valves leave the factory.
ODuring the warranty period, we will provide repair services or spare parts for damage caused by material or manufacturing process problems free of charge, excluding man-made damage.
We can provide installation and operation manuals.
The design standard of swing check valve is BS 1868/API 6D, the design standard of wafer check valve is API 594, and the design standard of forged check valve is API 602.
We have swing check valve, lift check valve/piston check valve, wafer check valve, lug type check valve, axial flow check valve/nozzle check valve/non slam check valve, tilting check valve, etc.
The check valve designed by BS1868/API6D/API602 has only metal-to-metal seat design, but the wafer check valve designed by API594 has metal-to-metal seat sealing design and soft sealing design.
Wafer dual plate check valve is divided into common type and retainerless type. The retainerless type is better than the common type. The retainerless type not easy to fall off, not easy to leak.
The metal-sealed check valve meets the leakage standard of API598, and the soft-sealed check valve can achieve zero leakage.
Metal sealed check valves are fireproof; soft sealed check valves are not.
No, the check valve is unidirectional.
Only the wafer check valve and the lift check valve have a spring, and the swing check valve does not have a spring.
We have bolted bonnet, pressure self-sealing bonnet, welded bonnet, thread bonnet and union bonnet.
There is no lifting ring design for the 1/2"-3" small size check valves, and there is a lifting ring design for the large size check valves.
Design standard: BS 1868/API 6D/API 594/API 602 Face to face standard: ASME B16.10 Flange standard: ASME B16.5/ EN1092-1/ASME B16.47 A/ASME B16.47 B BW standard: ASME B16.25 NPT standard: ASME B1.20.1 Pressure-temperature ratings: ASME B16.34 Pressure test: API 598/API 6D
We have check valves in BS1868 and AIP594 designs, we can customize on the original valve body according to customer's requirements.
Our soft-sealed wafer check valves can achieve zero leakage. Our hard-sealed check valves are factory pressure tested for zero leakage. According to the standard, the leakage class of the hard seal check valve is Class D.
Our BS1868 designed WCB material swing check valves are available in stock. Stock valve size range are 150LB: 2”~12”, 300LB: 2”~10”, 600LB: 2”~8”
We can produce check valves with 150LB~2500LB pressure.
For small size we have MOQ limit. For big size, 1 piece is okay.
Generally it is 5-10 working days if the goods are in stock. And it is 30-35 working days if produce new ones, it is according to quantity requirement.
The swing check valve can be installed horizontally or vertically, and the lift check valve is recommended to be installed horizontally.
When placing the pipeline, pay attention to the passing direction of the wafer check valve in the same direction as the fluid flow; install it in the pipeline that is placed vertically.
Check valve refers to a valve whose opening and closing part is a circular disc and acts by its own weight and medium pressure to block the backflow of the medium.
After receiving the order, we can provide ITP.
We can provide mating flanges upon request.
